Accurate Consistency Measurement: Monitors cement slurry thickening time in real-time under simulated downhole HTHP conditions, ensuring reliable well integrity.
Single-Cell Design: Compact and efficient, the single cell cement slurry consistency time measuring instrument simplifies operation while maintaining high precision.
HTHP Capability: Operates under extreme temperatures (up to 250℃ or 482℉) and pressures (up to 200MPa or 29,007psi), meeting API and ISO standards.
High Precision: Temperature Precision is ±1%; Pressure Accuracy is ±0. 5%.
User-Friendly Interface: Equipped with intuitive software for data logging, analysis, and report generation.
Durable Construction: High-grade materials ensure long-term reliability in demanding environments.
Safety: Consistency Alarm and Shut-down Protection.
Maximum Temperature | 250 ℃ / 482 ℉ |
Maximum Pressure | 200 MPa / 29,000 psi |
Thickening Time Range | 0 to 100 Bearden Units (Bc) |
Consistency Division | 1 Bc |
Slurry Cup Rotation Speed | 150 r/min±15 r/min |
Heater Power | 4,200 watts |
Pressure Medium | Special Oil for Consistometer |
Ambient Temperature | 3 to 55 ℃ / 37.4 to 131 ℉ |
Compliance | API Spec.10 |
Power | 110 or 220 VAC 50 Hz 5.5 kVA |
Compressed Air | 0.3 to 0.7 MPa / 43.5 to 102 psi |
Cooling Water | 0.2 to 0.6 MPa / 29 to 87 psi |
Dimensions | 850×750×1,700mm3 / 33×30×67 in3 |
Weight | 500kg / 1,100 lb |
Ideal for oil and gas drilling labs, this single cylinder consistometer is critical for optimizing cement slurry formulations, preventing premature setting, and ensuring wellbore stability.
Enhance your cement testing accuracy with the single cell pressurized consistometer – the trusted choice for HTHP consistency analysis.
